Denon 9.4 Channel AV Receiver for Home Theater Enthusiasts with Dolby Atmos - AVRX3800H
You may also like
With nine channels of amplification, up to four independent subwoofers, Dolby Atmos and DTS:X, plus IMAX Enhanced and Auro 3D, the AVR-X3800H envelops larger living spaces in theater-quality sound. Enjoy amazing 8K video quality and with HEOS® Built-in, wirelessly stream and share online music between rooms.
Enveloping 3D audio
Feel like you're in the center of the action with enveloping 3D sound.
Expert ready
You'll be amazed at the available configuration options to best fit your space.
Geared for 8K
Enjoy amazing video quality from the latest 8K technology available.
Optimize for your room
Enhance performance with room correction options from Audyssey (installed) or Dirac Live (optional upgrade available with future SW update).
High performance nine-channel amplifier
Discrete high-current amplifiers deliver up to 105W per channel (at 8 ohms, 20- 20kHz, THD 0.08%)—enough power to drive any speaker.
3D audio experience
Get enveloped in sound with Dolby Atmos®, DTS:X®, IMAX Enhanced and Auro 3D, along with Dolby Surround, DTS Neural:X and Auro-Matic upmixer to optimize legacy content.
Configuration flexibility
AVR-X3800H offers many setup options and flexibility to adjust your home theater to meet your needs. Supports 11.4 channel processing capability, Pre- Amplifier mode, and optional Dirac Live upgradability (with fee, coming soon in 2023).
Advanced 8K home theater
8K video is supported on all six HDMI inputs and two of the three outputs. Enjoy easy video compatibility and great picture quality with HLG, HDR, Dolby Vision, HDR10+, and Dynamic HDR passthrough.
GENERAL | |
---|---|
Weight in LBS | 27.6 |
Weight in LBS (Packaging) | 33.3 |
Maximum Dimensions Antenna: Horizontal: (W x D x H) in Inches Antenna: Vertical: (W x D x H) in Inches W/O Antenna: (W x D x H) in Inches | 17.1 x 15.3 x 6.6, ( 17.1 x 15.3 x 9.3 ), 【 17.1 x 14.9 x 6.6 】 |
Network Standby Consumption in W | Less than 2.0 |
CEC Standby Consumption in W | 0.5 |
Power Consumption in W | 660W |
Power Consumption No-Sound (ECO On / Off) in W | 60W/100W |
Standby Consumption in W | 0.1 |
Inputs Outputs | |
USB Audio, Made for iPod, Made for iPhone | Yes, No, No |
AM/FM Tuner | Yes |
Specifications | |
Number of Power Amps | 9 |
Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive) | 105W |
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) | 135W |
Power Output (6 ohm, 1 kHz, 10% 1ch Drive) | 215W |
GENERAL | |
System Remote Control | RC-1253 |
Pre-Programmed, Learnable, LCD Display | No, No, No |
Inputs Outputs | |
Front Inputs: Audio, Composite, Digital (Opt), HDMI, USB | No, No, No, No, Yes |
Speaker A / B | Assignable |
Bi-amp Drive | Assignable |
Multi-Room Speaker Terminal | Assignable |
Number of Speaker Terminals | 11 |
Multi-Room Out: Analog, Digital | 1, No |
Multichannel Preout | Yes (11.4) |
Subwoofer Out | 4 (independent) |
Speaker Terminal: Gold-Plated Screw, Regular Screw | No, Yes |
Digital In: Optical, Coaxial | 2, 2 |
Multi-Room Video Out: Video, HDMI | No, Yes |
Analog In, Out | 5, No |
Phono (MM) In | Yes |
OTHERS | |
Sleep Timer | Yes |
Inputs Outputs | |
HDMI In, Out | 6, 3 |
OTHERS | |
Auto Power Off | Yes |
Auto Speaker Setup by Microphone | Audyssey MultEQ XT32, Dirac Live (upgrade) |
Front Display | 1-Line FLD |
GUI Languages | 3 |
Setup Assistent | Yes |
Quick Select Plus, Quick Select | Yes, No |
Variable Crossover | Yes |
Optimized Bass Redirection | Yes |
Bass Sync | Yes |
ECO Mode | Yes |
Multi-room CI | |
HDMI Diagnostics | Yes |
IP Control, RS232 Control, Web Control, App Control | Yes, Yes /Yes, Yes |
Remote In / Out | Yes, Yes |
DC Trigger Output | 1 |
Zone HDMI Output from HDMI Source | Yes |
Zone Audio Output: Speaker, Pre-Out | Yes, Yes |
HDMI | |
Auto LipSync | Yes |
Multi-room CI | |
Multi-Room Zones | 2 |
Zone Audio Source: HDMI; Optical, Coax, Network, USB; Analog | Yes (2ch), Yes (2ch), Yes, Yes |
HDMI | |
ALLM (Auto Low Latency Mode) Pass-through for gaming | Yes |
Variable Refresh Rate, Quick Flame Transport, Quick Media Switching | Yes, Yes, No |
3D Signal Pass-through | Yes |
8K Signal Pass-Through, Scaling, GUI Overlay | Yes, Yes, Yes |
DSD Audio Capability | Yes |
Audio Return Channel (ARC), Enhanced ARC | Yes, Yes |
HDMI 2.1: 8K/60Hz AB, 4K/120Hz AB | Yes, Yes |
HDR, HLG, Dolby Vision, HDR10+, Dynamic HDR | Yes , Yes, Yes, Yes, Yes |
HDMI Inputs: Back, Front | 6, No |
HDCP2.3 support | Yes |
HDMI Outputs: Main, Zone | 2, 1 |
Network | |
Wi-Fi | Yes |
Bluetooth | Yes |
Ethernet Ports | Yes |
Roon Tested | Yes |
HEOS App Control | Yes |
Compatible with Remote APP for Smart Phones | Denon 2016 AVR Remote |
Pandora | Yes |
SiriusXM* | Yes |
DSD Audio Streaming | Yes (2.8/5.6MHz) |
AirPlay 2 | Yes |
TuneIn | Yes |
Spotify Connect | Yes |
Lossless Formats: FLAC HD, WAV, ALAC (all 192kHz/24 bit) | Yes, Yes, Yes |
Sound Enhancements | |
Audyssey LFC | Yes |
Dirac Live Upgradability | Yes |
Compressed Audio Restorer | Yes |
Network | |
Media Server | Yes |
HEOS Wireless Multi-Room Technology | Yes |
Alexa / Google Voice Assistant / Apple HomePod | Yes, Yes, Yes |
Lossy Formats: MP3, WMA, AAC | Yes, Yes, Yes |
Lossless Formats: FLAC, ALAC, WAV | Yes, Yes, Yes |
Sound Enhancements | |
Audyssey Dynamic EQ, Dynamic Volume | Yes, Yes |
Discrete Power Amplifier | Yes |
Pure Direct | Yes |
Audyssey | MultEQ XT32 |
Multichannel Surround | |
Max. Number of Processing (Pre-Amp) Channels | 11.4 |
Multichannel Stereo | Yes |
Auro 3D | Yes |
360 Reality Audio / MPEG H | Yes, Yes |
DTS HD Master, DTS:X, DTS:X Pro | Yes, Yes, No |
DTS Neo:X, DTS Neural:X | No, Yes |
DTS Virtual:X | Yes |
IMAX Enhanced | Yes |
Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Atmos Music | Yes, Yes, Yes, Yes |
