DESIGN
The Aesthetic Series epitomizes fluidity of design and power of performance. Created for those who demand precision and clarity from their music and film soundtracks, the A 804 provides a unique wall-mount solution for home theater systems.
Jamo has a long tradition of loudspeaker innovation. Groundbreaking thinking has led to the development of an outstanding front speaker that, despite its compact size, delivers a convincing and highly detailed full-frequency range that's normally the domain of much larger speakers.
The A 804 not only sounds great, it also has an exciting contemporary look. The unique black leather finish makes it extremely attractive for most homes; the shapely cabinet and the mounting system make it the perfect match for virtually any modern flatscreen.
TECHNOLOGY
The A 804 is a 3-way, bassreflex speaker. The rigid cabinet with the top and bottom constructed from high-gloss, lacquered aluminum and the rest made from steel and high-density polymer results in a stable, non-resonant cabinet with very clean sound reproduction.
One of the secrets of the A 804 lies in its flow-optimized bass port, which delivers extremely clean bass, even at high volume. The silk dome midrange/tweeter is a Jamo developed co-axial unit featuring WaveGuide technology. The clever three-way construction of the A 804 produces a perfect sound dispersion pattern, giving you maximum freedom when positioning your flatscreen, surround system and sofa.
The high-style Jamo A 804 wall-mounted loudspeaker is packed with high-performance features:
WaveGuide tweeter faceplate design controls sound pattern for open, dynamic sound.
A coaxial drive unit that sends all sound to your ears simultaneously
The unique rigid cabinet reduces sound radiation inside the speaker
The A 804"it simply sounds as amazing as it looks.
Specifications | |
---|---|
System Type | 3-way bassreflex |
Impedance | 6 |
Weight (Kg/lb) | 5.9 / 13.0 |
Tweeter (mm/in) | 19 / ¾ |
Woofer (mm/in) | 2 x 114 / 4½ |
Product dimensions (mm/in, HxWxD) | 700 x 160 x 100 / 27.6 x 6.3 x 3.9 |
Product Finish | High-Gloss Black or White Lacquered Aluminum |
Frequency Response (Hz, +/-3dB) | 70 - 20,000 |
Power Handling (Watts Long/Short Term) | 80 / 120 |
Sensitivity (dB, 2.8V/1m) | 87 |
Midrange (mm/in) | 114 / 4½ |
