Pioneer 5.2-Channel AV Receiver - VSX-534(B)

SKU : VSX-534(B)

$399.99 CAD

Literature
  • Dolby Atmos/Dolby Surround Upmixing/Dolby Atmos Height Virtualizer
  • DTS:X/DTS Neural:X Upmixing/DTS Virtual:X
  • Supports pass-through for 4K HDR10, HLG (Hybrid Log-Gamma), and Dolby Vision signals
  • 150 W/ch (6 ohms, 1 kHz, THD 10 %, 1ch Driven)
  • 80 W/ch (8 ohms, 20 Hz-20 kHz, THD 0.08 %, 2ch Driven, FTC)
  • 12% slimmer size than the previous model


Dolby Atmos/Dolby Surround Upmixing

The VSX-534 is compatible with 3.1.2ch configuration of the latest theater sound platform, Dolby Atmos. You can reproduce object-oriented sound in smooth, curving movements, or the realistic three-dimensional movement overhead by the top speakers. Other audio codecs such as PCM and DSD can be upmixed using Dolby Surround for enjoying 3D surround sound.

DTS:X/DTS Neural:X Upmixing

DTS:X is the next-generation audio codec from DTS that leverages object-based audio to enable new immersive and interactive audio experiences. Since DTS:X can automatically adapt the audio to the existing channels and speaker system, no specific speaker layout is required. Experience an immersive soundscape with incredibly rich and life-like audio. Other audio codecs such as PCM and DSD can be upmixed using DTS Neural:X for enjoying 3D surround sound.

Dolby Atmos Height Virtualization

When playing any Dolby format, engaging the Dolby Atmos Height Virtualizer enables a more immersive listening experience, creating a virtual surround and height effect from traditional speaker layouts without employing additional surround or height speakers.

DTS Virtual:X

With DTS Virtual:X, you can enjoy a three-dimensional immersive sound similar to DTS:X, without the need of height or rear speakers. The technology supports 2 to 7.1.4-channel input source, for delivery on 2 to 5.1-channel speaker layout. DTS Virtual:X works with all DTS codecs, including DTS:X.

Next Generation Video Standard Ready

The VSX-534 supports pass-through for HDR10, HLG (Hybrid Log-Gamma), and Dolby Vision signals. By connecting a compatible source device, you can enjoy these latest video standards on a compatible display. What's more, all HDMI terminals support 4K (60p/4:4:4/24-bit), Wide Color Gamut (BT.2020), and HDCP 2.2, so you will have no problem when upgrading to new devices, and can also enjoy premium content such as 4K videos with digital copy protection.

MCACC Auto Room Tuning

Create the optimum acoustic environment with Pioneer's MCACC (Multi-Channel Acoustic Calibration System), developed with the expertise of professional recording studios. With the custom microphone, the system automatically compensates for differences in speaker size, level and distance, and equalizes response.

Zone B Output for Wireless Headphones

The VSX-534 is equipped with Zone B audio output terminals for expanding the Main Zone sound by connecting your wireless headphone dock. You can listen to the sound playing in the living room via wireless headphones.

Built-in Bluetooth Wireless Technology

Stream songs from compatible devices with the built-in Bluetooth Wireless Technology (ver. 4.2 LE). The VSX-534 features A2DP/AVRCP profiles, with support for SBC/AAC codecs. By pressing the Bluetooth button on the front panel, you can directly start up the BT function, even when the unit is in standby.

Personal Preset

Just press the Personal Preset button on the front panel for three seconds, and your current settings such as volume level and listening mode can be saved. Up to three presets can be registered and easily called up from the front panel button or the remote control.

Dialog Enhancement

With this unique mid-range sound control feature, you can make independent volume adjustments to the range including dialogs in films, with the up/down key on the remote control.

On-Screen Information for Audio/Video Status

The screen display now shows detailed input and output information for the playing content. So you can see whether your video is being output by Dolby Vision, or if the movie is processing Dolby Atmos or DTS:X sound.

HANDHELD AND INTERNET
Streaming Audio From PC/NetworkYes
Internet RadioYes
DECODERS & FORMATS
Digital Core DSP EngineDigital Quad-Core 32-bit DSP (Cirrus Logic)
Audio DACs384 kHz/32-bit D/A Conversion with AK4438 (AKM)
Audio Processing-
iPod Digital Audio-
Music File Playback192 kHz/24-bit ALAC, AIFF, FLAC, WAV Via USB
High-Definition Copy Protection (HDCP)2.2
Dolby AtmosYes
Dolby TrueHDYes
Dolby Digital PlusYes
DTS:XYes
DTS-HD Master AudioYes
DTS Neural:XYes
HDMI SACD Transfer2 Channel
SOUNDFIELD CALIBRATION
Phase ControlYes
MCACCYes
MCACC Memory1
Standing Wave Control-
EQ Bands9-Band
Symmetric EQYes
X-Curve-
Distance Adjustment0.1 feet
Polarity Check-
Auto Subwoofer CrossoverYes
LISTENING MODES
Auto SurroundYes
Stream DirectYes (Direct, Pure Direct)
Advanced Surround10+1
Wide Surround-
Front Stage Surround AdvanceYes
Headphone Surround-
Virtual Speakers-
Audio Features
Dialog EnhancementYes
Advanced Sound RetrieverYes
Sound Retriever AIR-
Digital Noise Reduction-
Tone ControlMulti
Sound Delay (Lip Sync)Yes
Speaker A/B-
Bi-AmpYes
VIDEO PROCESSING
4K Ultra HD Pass-ThroughYes (HDR10, HLG and BT.2020 Wide Color Gamut Signal Pass-through)
4K Ultra HD Video ScalerUltra HD Upscaling
3-D ReadyYes
Audio Return ChannelYes
HDMI Standby ThroughYes with Input Switch / Last Memory
HDMI 36-bit Deep ColorYes
HDMI x.v. ColorYes
Video Processor-
Video Converter to HDMIYes
Component Video Scaler-
Composite Video Scaler-
Pure Cinema I/P Converter-
Advanced Video Adjustment-
3D Noise Reduction-
Super ResolutionYes
Connectivity
HDMI Input / Ωutput4 In (Rear) / 1 Ωut
MHL 2-
Wi-Fi Built-In-
Bluetooth Built-InYes (Version: 4.2 + LE, Profile: A2DP 1.2/AVRCP 1.3, Codec: SBC/AAC)
Wireless Adapter Port-
Bluetooth Adapter Port-
Component Video Input / Ωutput-
Composite A/V Input / Ωutput-
iPhone / iPod / USB Memory Input-
USB TerminalFront and Rear
Ethernet Input-
Analog Audio Inputs / Ωutput2 in / 0 out
Digital Audio Inputs / Ωutput2 In (Ωptical 1, Coaxial 1)
Pre-Amp Ωutput0.2 ch.
Headphone ΩutputYes
Front A/V InputsUSB / 3.5mm stereo mini jack
AM/FM PresetsAM/FM Tuner 40 Presets
INSTALLATION
Ωn-Screen DisplayUser-Friendly GUI with System Setup Menu
Auto Power DownYes
Multi-Room and Source Ωutput-
IR Serial Remote In/Ωut-
Multi-Zone Ωn-Screen Display-
FL DimmerYes
Function Rename-
RemoteYes
Sleep TimerYes
Versatile Speaker ConfigurationFRΩNT, CENTER, SURRΩUND/HEIGHT
CONSTRUCTION
Front PanelBrushed
Speaker Terminals2 large + 3 clip
Warranty
Warranty1 Year Parts & Labor
Dimensions
W x H x D (inches)Wi-Fi Antenna's Up-
W x H x D (inches)17-1/8 x 5-13/16 x 12-5/8
Weight17.6
